The Grundfos ALPHA2 / ALPHA3 family of auto-adapting circulator pumps sets the benchmark for energy-efficient hydronic circulation, with AUTOADAPT control that continuously matches pump performance to actual system demand and input power from just 3 W (EEI down to 0.15). A permanent-magnet motor, ceramic shaft and bearings, dry-running protection and high-torque start deliver quiet, maintenance-free operation, while the ALPHA3 adds built-in Bluetooth and flow-based hydronic balancing through the Grundfos GO Balance app. Applications include residential and light-commercial heating systems, radiator and underfloor heating circuits, air-conditioning and cooling circuits, and domestic hot-water recirculation with stainless-steel N versions.

Flow Rate :

Up to 3.6 m3/h

Head :

Up to 8 m (4 m / 5 m / 6 m / 8 m variants)

Power Input :

3 - 50 W, EEI as low as 0.15

Power Supply :

1 x 230 V +/-10%, 50/60 Hz

Max Fluid Temperature :

+2 C to +110 C

Max System Pressure :

10 bar (PN 10)

Material :

Cast iron (EN-GJL-150) or stainless steel (N) housing, composite PES impeller, stainless steel rotor can

Connections :

G 1 / G 1 1/2 / G 2 (DN 15 / 25 / 32), 130 or 180 mm port-to-port
